FBC 9th Edition Window Schedule for Flood Zone Properties (AE, VE, X)

Every window on a Pinellas property has to be impact-rated or protected by an approved shutter system under the FBC 9th Edition, and here's what nobody tells you at the window showroom: your FEMA flood zone doesn't change that wind requirement, but it changes three other things that drive the final budget. Sill height above design flood elevation, frame-material corrosion rating, and whether the 50% Rule forces replacement of otherwise-serviceable windows all swing on your AE, VE, or X designation.

Impact-rated glass must pass ASTM E1996 (large-missile test in most of Pinellas), carry a Florida Product Approval number (FL#) or Miami-Dade NOA, and the label must be visible at final inspection. Below is the window schedule by flood zone, the code sections that drive each requirement, and when the 50% Rule pulls windows into a compliance obligation. If your project is close to that threshold, run it through the FEMA 50% Rule calculator first.

We're Revolution Contractors, a St. Petersburg licensed general contractor (both Revolution Contractors LLC licenses, CRC1331628 and CGC1522463). This piece walks the schedule by zone so you can price windows against the right rules before you commit scope.

The Three Axes: Wind Zone, Flood Zone, and 50% Rule

Three separate code layers govern windows on a Pinellas property. Understanding which layer drives which requirement keeps the schedule straight:

• Wind zone (FBC Section 1609.1.2). Pinellas is entirely in the wind-borne debris region. Every replacement or new window has to be impact-rated or protected by an approved shutter system, regardless of flood zone. Design wind pressures come from ASCE 7-22 under the 9th Edition (was ASCE 7-16 under the 7th).
• Flood zone (FBC Section 1612.2, ASCE 24-24). Your FEMA flood zone (X, AE, or VE) determines whether window sill heights, frame materials, and installation details face additional flood-related rules. X zones skip most of this layer; VE zones face the most.
• 50% Rule (local floodplain ordinance). If a remodel exceeds 50% of pre-improvement structure value, the entire building including windows must meet current flood and wind code. Windows that were legal-nonconforming become non-compliant and must be replaced.

Every window schedule question below sits on some combination of these three layers.

Windows in X Zones (Outside the Special Flood Hazard Area)

X zone means FEMA has not designated your property as a special flood hazard area. In Pinellas, X zones cover most of the higher-elevation inland areas: parts of central St. Petersburg, portions of Seminole, most of Pinellas Park.

Window schedule under the 9th Edition in an X zone:

• Impact rating or shutters required (wind-borne debris region). ASTM E1996 large-missile test, FL# label, visible at final inspection. For a full remodel scope walkthrough, see home remodel services.
• No sill height requirement from flood code. Sill heights follow egress rules (bedroom emergency escape openings) and standard fenestration requirements only.
• Frame material unrestricted from flood code. Vinyl, aluminum, wood, and fiberglass frames all acceptable. Coastal-3,000-foot corrosion requirements do not apply.
• 50% Rule does not apply. Substantial improvement is a flood-zone concept; X-zone properties skip this layer entirely.

Practically: in an X zone, a window replacement project's only real 9th Edition constraint is impact rating with proper labeling and installation.

Windows in AE Zones (Special Flood Hazard Area, Non-Coastal)

AE zone is the most common flood-hazard designation in Pinellas. Base flood elevation (BFE) is defined in feet above sea level, wave action is not the primary hazard (that's V/VE zones), and the freeboard requirement in Pinellas is BFE +1 foot.

Window schedule under the 9th Edition in an AE zone:

• Impact rating or shutters required (WBDR, same as X zone).
• Sill height above BFE +1 for windows in enclosed areas below elevated living space. Enclosures below the elevated first floor (used for parking, storage, or building access only) must have flood vents, not windows. Windows in the elevated living space above BFE +1 have no flood-driven sill requirement.
• Frame material generally unrestricted below coastal 3,000-foot zone. Above the elevated floor, frame material follows standard fenestration rules. Below the elevated floor, no windows should be installed (flood vents only).
• 50% Rule applies. A remodel exceeding 50% of pre-improvement value forces the entire structure (including window replacement) to current code. Non-impact-rated windows installed under an older code become non-compliant.
• Coastal 3,000-foot corrosion rule may apply. If the AE-zone property is within 3,000 feet of saltwater (much of Snell Isle, Shore Acres, downtown St. Pete waterfront), window fasteners and any exposed metal hardware need Type 316 stainless steel or equivalent corrosion resistance.

Windows in VE Zones (Coastal High-Hazard Area)

VE zone is the coastal high-hazard designation, where wave action is a primary hazard in addition to still-water flooding. Base flood elevation includes a wave height component. Most VE-zone Pinellas properties are on the barrier islands (Treasure Island, Madeira Beach, Redington Beach, Indian Shores, St. Pete Beach) and some direct-Gulf shoreline.

Window schedule under the 9th Edition in a VE zone:

• Impact rating or shutters required (WBDR).
• All habitable space and enclosed areas must be above BFE +1. Below the elevated floor, only breakaway walls (no permanent enclosure) with flood vents, no windows. This is enforced more strictly under ASCE 24-24 than under ASCE 24-14.
• Frame material and corrosion rating tighten. Coastal 3,000-foot corrosion rule almost always applies in VE zones. Type 316 stainless steel fasteners or hot-dip galvanized 3.0 oz/ft² minimum for exposed metal. Frame material must resist saltwater corrosion: aluminum with marine-grade anodizing, fiberglass, or high-grade PVC.
• 50% Rule applies with tighter compliance standard. Substantial improvement in a VE zone triggers elevation and V-zone-equivalent design under ASCE 24-24, which is materially more expensive than under ASCE 24-14. Window replacement in a substantial improvement scenario would be one line item within a full elevation project.
• Breakaway wall design provisions updated. If your project includes a breakaway wall system that historically had window openings (some older beach homes), those openings have to be redesigned as flood vents or eliminated.

Windows in Coastal A Zones / LiMWA (The Gray Zone)

Coastal A zone (also called LiMWA, Limit of Moderate Wave Action) is a subset of AE zone where FEMA modeling shows wave heights between 1.5 and 3.0 feet. Under ASCE 24-14 (referenced in the 7th and 8th Editions), Coastal A zones were interpretive: some jurisdictions applied V-zone-equivalent design, some did not. Under ASCE 24-24 (referenced in the 9th Edition), Coastal A zones explicitly require V-zone-equivalent design.

Pinellas has extensive Coastal A zone mapping, particularly on the sound side of the barrier islands and portions of Snell Isle and Shore Acres. Under the 9th Edition, if your property is in a Coastal A zone, the window schedule follows the VE zone rules above, not the standard AE rules.

This is the biggest 9th Edition change for coastal Pinellas homeowners. Properties that were treated as AE under the 7th and 8th Editions may be treated as VE-equivalent under the 9th if they fall inside the LiMWA line. Check the flood map carefully.

Impact-Rated Glass Thresholds and WPI Certification

Impact-rated glass in Pinellas has to pass two ASTM tests:

• ASTM E1996 (large-missile impact). A 2x4 lumber missile fired at the glass at approximately 34 mph (50 feet per second). This is the large-missile test required for windows within 30 feet of the ground in the WBDR. Most Pinellas residential windows fall in this category. If you're pairing window upgrades with wind mitigation, the MSFH vs Citizens breakdown shows how insurance credits stack.
• ASTM E1886 (cyclic pressure). After the impact test, the glass is subjected to 9,000 cycles of pressure loading simulating hurricane wind cycling. The glass has to remain in the frame with no breach.

Glass that passes both tests is labeled “large missile impact” and gets a Florida Product Approval number (FL#) issued by the Florida Building Commission. Products originally approved for Miami-Dade high-velocity hurricane zone use may also carry a Miami-Dade Notice of Acceptance (NOA); those products meet or exceed FL# requirements.

WPI (Window Pressure Index) is not a standard FBC term but is sometimes used colloquially to describe design pressure ratings. What actually matters under the code is:

• Design pressure (DP) rating. Each window has a positive and negative design pressure rating (e.g., DP +50 / -55 psf). The project's structural engineer or the WMHIP (wind mitigation home inspection provider) calculates the required DP based on the site's design wind speed and the window's tributary area under ASCE 7-22. See the FBC 2026 vs 2020 comparison for what changed in the wind design standard.
• Component and cladding load compliance. The window's DP rating has to meet or exceed the calculated load. Higher-elevation openings and corners generally see higher loads.

For most Pinellas residential replacement projects, DP +50 / -55 or DP +55 / -60 impact-rated windows cover typical loads. Custom homes with large curtain-wall glass require project-specific engineering.

When the 50% Rule Triggers Window Replacement

Windows sit inside the 50% Rule two ways:

• As part of the improvement cost. New windows installed as part of a remodel count toward the 50% threshold. High-end impact-rated windows on a whole-house replacement can add $30,000 to $80,000 to a project cost, which pushes many otherwise 49% projects past the threshold.
• As part of the compliance obligation when substantial improvement is triggered. If your remodel exceeds 50% and triggers substantial improvement, non-compliant windows (older non-impact-rated units installed under prior code) become part of the compliance obligation. They must be replaced with impact-rated units meeting current code as part of the substantial improvement work.

Practically, this means window replacement decisions in flood zones need to be sequenced with the overall remodel budget. A common pattern: homeowner plans a kitchen and bath remodel, adds impact windows because “we're already in there,” and inadvertently pushes the project over 50%, triggering elevation as part of substantial improvement.

For a deeper walkthrough of how the 50% Rule works and how to stay under (or clear the threshold with eyes open), see the FEMA 50% Rule guide.

Product Examples (Not Endorsements)

Products commonly specified for Pinellas flood-zone window schedules under the 9th Edition include lines from PGT (WinGuard series), CGI (Sentinel and Estate lines), Andersen (A-Series impact), Marvin (Impact-Ultimate), and Custom Window Systems (CWS Ultra Series). This is not an endorsement. Product selection depends on your project's specific design pressures, frame material requirements, budget, aesthetic goals, and product availability. All listed manufacturers publish current Florida Product Approval numbers on floridabuilding.org.

What matters more than brand:

• FL# or NOA is current for the product line and configuration being specified.
• DP rating meets or exceeds the calculated load for the specific opening.
• Frame material appropriate for coastal exposure if within 3,000 feet of saltwater.
• Installer certified for that manufacturer's system and following the manufacturer's installation instructions exactly. Installation errors (wrong anchor spacing, missing sealants, incorrect shim placement) can void the impact rating even with a compliant product.

Your general contractor and the window supplier should confirm all four points before ordering.

The Takeaway

The play we see work in Pinellas: pull your FEMA flood map and confirm your zone (X, AE, VE, or Coastal A) before you talk to any window supplier. The schedule above tells you what questions to ask next: sill height above DFE, Type 316 stainless fasteners inside the 3,000-foot coastal zone, and whether your overall remodel budget pushes you across 50%. If you want us to walk the house with your flood zone pulled and tell you which window spec actually works for your scope, call (727) 888-6161.
